Aerospace fire testing
Warringtonfire operates aerospace fire testing from our reaction to fire laboratories in Frankfurt and Warrington. Our Frankfurt laboratory is one of the few laboratories in the world that have the kerosene seat burner and is Airbus accredited.
Our Warrington laboratory is UKAS accredited and our Frankfurt laboratory is DAkkS accredited, both laboratories hold ISO / IEC 17025 accreditation. Our Frankfurt laboratory is officially recognized by the Luftfahrtbundesamt (LBA) and as such Warringtonfire is authorized to conduct official aerospace fire testing in accordance with FAR 25.853. We are also Airbus accredited and help with our testing to improve the materials of our customers in case of fire.
- Our aerospace fire testing capabilities include:
- Vertical fire test (12 s or 60 s), FAR/JAR/CS 25.853 b(4), (App F to part 25 part I § (a),(1) (ii)=12s, (i)=60s, respectively ABD 0031- 7.1.2
- Smoke development test, FAR/JAR/CS 25.853 (d), (App. F to part 25, part V), respectively ABD 0031- 7.3.1
- Toxicity-test, ABD 0031- 7.4
- Smoke development test BSS 7238
- Toxicity test BSS 7239
- Kerosene-burner-test model-seat, FAR/JAR/CS 25.853 (c, App. F to part II)
- Horizontal fire test (ignition time: 15 s), FAR/JAR/CS 25.853 b(5), (App. F to part 25 part I § (a),(1) (iv) // (v), respectively ABD 0031- 7.1.3 // -7.1.4
- For aircraft cargo compartment lining materials (kerosene burner) according to FAR/JAR/CS 25.855 (App. F to part III)
- 45°-Test according to FAR/JAR/CS 25.853 (d), (App. F to part 25, part I § (6)) bzw. ABD0031- 7.1.5
Why aerospace fire testing?
The fire behavior of a burning object influences the escape possibilities of people and if even if aerospace fire testing is not required by law, more and more insurance and official bodies require the monitoring and improvement of fire protection. For this purpose, certain fire tests are necessary.
In order to monitor the fire behaviour, we can carry out various aerospace fire testing which measure the flammability, flame, heat and smoke development and the flue gases. As one of the leading fire test laboratories, we not only help our customers to better understand and improve their product, but also gain market advantage over the competition.
